Category :
Transmission
Ref : 63190
Family :TR
ABS on the vehicle : Yes
Compressed length : 965 mm
Height : 25 mm
Nut type : Washer
Thread pitch type : 22X150
COTE BOITE
Diameter (big) : 80 mm
Diameter (little) : 20 mm
Seal seat diameter : 35 mm
Outer spline diameter : 24 mm
Housing diameter : 82 mm
Length : 85 mm
Length of the gearbox output without seal seat : 57 mm
Number of external splines : 22
Number of grooves : 1
Type of material : NITRILE
COTE ROUE
Diamètre (grand) : 73 mm
Diamètre (petit) : 21 mm
Diamètre des cannelures extérieures : 26.8 mm
Diamètre du bol : 79.1 mm
Shoulder diameter : 52 mm
Longueur : 91 mm
Nombre de cannelures extérieures : 33
Number of splines on inner race : 22
Type and position (snap ring/circlip) : Centered snap ring
Type de matière : NÉOPRÈNE
| Sealing kit | COTE ROUE | S5025 |
|
| COTE BOITE | S5017 |
|
|
| Fixation | COTE ROUE | ATEC011 |
|
| CV joint | COTE BOITE | ATCBMO19 |
|
Equivalence to manufacturer references
GENERAL MOTORS : 13367050
GENERAL MOTORS : 39083852
GENERAL MOTORS : 95522349
GENERAL MOTORS : 95524081
