HYUNDAI TUCSON II D

Ref : 54570

Family :TR

Compressed length  : 590 mm

ABS on the vehicle  : Yes

COTE ROUE

Number of external splines  : 30

Type and position (snap ring/circlip)  : Centered snap ring

Shoulder diameter  : 73 mm

Outer spline diameter  : 31 mm

Number of splines on inner race  : 25

Diamètre du bol  : 95 mm

COTE BOITE

Housing diameter  : 81.3 mm

Minor diameter of the splines  : 29 mm

Number of internal splines  : 28

CV joint COTE ROUE JHHY57
Sealing kit COTE ROUE S5005 SOUFFELT C/R
S5026 AUDI
COTE BOITE S6287
S6194 C/B
Fixation COTE ROUE ATEC021

Equivalence to manufacturer references

  • HYUNDAI : 49501D7030
